TDA1517; TDA1517P
2 x 6 W stereo power amplifier
Product specification
Supersedes data of 2002 Jan 17
2004 Feb 18
NXP Semiconductors
2 x 6 W stereo power amplifier
Product specification
TDA1517; TDA1517P
FEATURES
• Requires very few external components
• High output power
• Fixed gain
• Good ripple rejection
• Mute/standby switch
• AC and DC short-circuit safe to ground and VP
• Thermally protected
• Reverse polarity safe
• Capability to handle high energy on outputs (VP = 0 V)
• No switch-on/switch-off plop
• Electrostatic discharge protection.
GENERAL DESCRIPTION
The TDA1517 is an integrated class-B dual output
amplifier in a plastic single in-line medium power package
with fin (SIL9MPF), a plastic rectangular-bent single in-line
medium power package with fin (RBS9MPF) or a plastic
heat-dissipating dual in-line package (HDIP18). The
device is primarily developed for multi-media applications.
QUICK REFERENCE DATA
SYMBOL
VP
IORM
Iq(tot)
Isb
Isw
|ZI|
Po
SVRR
αcs
Gv
Vno(rms)
Tc
PARAMETER
supply voltage
repetitive peak output current
total quiescent current
standby current
switch-on current
input impedance
output power
supply voltage ripple rejection
channel separation
closed loop voltage gain
noise output voltage (RMS value)
crystal temperature
CONDITIONS
RL = 4 Ω; THD = 0.5%
RL = 4 Ω; THD = 10%
fi = 100 Hz to 10 kHz
MIN.
6.0
−
−
−
−
50
−
−
48
40
19
−
−
TYP.
14.4
−
40
0.1
−
−
5
6
−
−
20
50
−
MAX.
18.0
2.5
80
100
40
−
−
−
−
−
21
−
150
UNIT
V
A
mA
μA
μA
kΩ
W
W
dB
dB
dB
μV
°C
ORDERING INFORMATION
TYPE NUMBER
TDA1517/N3
TDA1517/N3/S5
TDA1517P
NAME
SIL9MPF
RBS9MPF
HDIP18
PACKAGE
DESCRIPTION
plastic single in-line medium power package with fin; 9 leads
plastic rectangular-bent single in-line medium power package with
fin; 9 leads
plastic heat-dissipating dual in-line package; 18 leads
VERSION
SOT110-1
SOT352-1
SOT398-1
2004 Feb 18
2
NXP Semiconductors
2 x 6 W stereo power amplifier
BLOCK DIAGRAM
Product specification
TDA1517; TDA1517P
handbook, full pagewidth
non-inverting
input 1
1
supply voltage
ripple rejection
output
3
mute switch Cm
60
kΩ
VA
2
kΩ
18 kΩ
VP
stand-by
switch
VA
15 kΩ
x1
15 kΩ
mute
reference
voltage
18 kΩ
4
output 1
power stage
stand-by
reference
voltage
8 mute/stand-by
switch input
mute
switch
TDA1517
non-inverting
input 2
2
kΩ
9
60
kΩ
input
reference
voltage
VA 6
mute switch Cm
signal
ground
2
7
SGND
VP
power stage
power
ground
5 (substrate)
MLC351
PGND
output 2
2004 Feb 18
Fig.1 Block diagram.
3
|
